Water and beverage preform mold, Edible oil preformmold, Preform Mold for cosmetic and personal care bottle. Preform Mold for pesticide bottle, Preform Mold formedicine bottle.
Water and beverage preform mold, Edible oil preformmold, Preform Mold for cosmetic and personal care bottle. Preform Mold for pesticide bottle, Preform Mold formedicine bottle.
We are a bottle blowing machine manufacturer. We are committed to offering customized solutions for the market and customers, whether individual products or complete sets of equipment. Although the market, application, and customers are different, we have a unique concept to guide the success of customers.pet bottle blow moulding machine price is suitable for producing PET/PE and PP plastic containers
| TYPE | ITEM | ZS-20L |
| Machine | Product volume | 20L |
| Product capacity | 200-300pcs/h | |
| Product diameter | ≤65mm | |
| Template size | 420x660mm | |
| Thickness | 350-420mm | |
| Clamping stroke | ≤350mm | |
| Clamping force | 80KN | |
| Max. stretching stroke | 530mm | |
| Working pressure | ≤1.0Mpa | |
| Blow bottle Pressure | ≤4.0Mpa | |
| Blow bottle power | 2Kw | |
| Machine weight | 2500Kw | |
| Machine dimension | 2800*720*2160mm | |
| Heater | Power | 10Kw |
| Weight | 800Kg | |
| Dimension | 2200*750*1800mm |
We manufacturer a wide range of fully automatic PET bottle machine including 3-cavity automatic PET bottle blow molding machine with capacity 2500 bottles per hour, 4-cavity economical automatic PET bottle blow molding machine with capacity 4500 bottles per hour, high efficiency 4-cacity automatic PET blow moulding machine with capacity 5500 bottles per hour, 6-cavity automatic PET bottle manufacturing machine with capacity 7500 bottles per hour and 8-cavity automatic PET bottle blowing machine with capacity 10000 bottles per hour.
[Browse Our Machine Selection]
Our ZSM series Full Automatic Stretch Blow Molding Machine offers two cavities, one and six, for a variety of production sizes depending on your operations. This machine produces containers with a two-liter maximum, ideal for all kinds of wide-mouth and PET bottles for edible oils, medicines, beverages, cosmetics.
This Blow Molding Machine utilizes a high-speed linear blow molding mechanism for PET bottles of all types. We applied our advanced bottle-blowing technology to develop superior automation facilities and high production efficiency, safety, stability, and reliability. This device works as a mineral water bottle blowing machine just as well as an oil bottle blowing machine.
This machine’s double stations and linear guide movement improves the quality of bottle production. We developed this machine to utilize high-intensity stainless steel mold platens and run on hydraulic pressure. Our superior designs and analyses ensure a secure production, utilizing finite element aided software for a digitally controlled procedure.
The ZS-H400 Automatic blow molding machine is suited for Max 2L PET bottles. Our technology and engineering allow this machine to yield 4,000 bottles per hour. This high productivity pairs with low energy consumption and compact machine size. We can discuss a customized mold to meet a client’s unique goals.
This machine’s automatic bottle embryo process offers low labor and energy costs while maintaining high efficiency and profit. With an automatic alarm, fault detection, and judgment function, maintenance is fast and easy. Our partners supply accessories to customize the machine according to a company’s unique operations.
Our ZS-2000 full-automatic PET bottle blow molding machine is a stable two-step automatic machine. With both two and six cavities, it yields around 1,250 bottles per hour per cavity. It offers an easy installment and startup process to produce between 0.6L and 2L volume bottles.
